Industrial control panels consist of power circuits or control circuits (or both) which provide signals that direct the performance of machinery or equipment. Industrial control panels don’t include the main power, nor do they include the controlled equipment; rather, the panel is mounted on a back panel (or subpanel) or in an enclosure, depending on the application. Industrial control panel design begins with weighing design requirements and specifications and preparing schematics, but the design process can be quite complex in order to ensure that all applicable regulatory standards and safety requirements are met.
We’ve created this guide to provide an overview of the key design considerations applicable to industrial control panel design, including schematics, relevant regulatory standards, and design considerations relating to every facet of effective control panel design for industrial equipment and machinery.
